Hollow Glass Microspheres
- Product No.：2020529233532
High-performance hollow glass microsphere is a kind of ultra-lightweight inorganic non-metallicmaterial with hollow structure. It is a versatile and high-performance new lightweight material developed in recent years. It owns features with light weight, large bulky, low thermal conductivity, high compressive strength, smoothly mobility etc. It can be used in paint and coatings, rubber, plastics, FRP, artificial stone, putty and other products as filler and weight-reducing agent. Because of its high compressive properties, it can be used to produce high-strength, low-density cement slurry and low-density drilling fluid in oil and gas extraction industry.
Applications: Its applications are in the fields of thermal insulation coating, putty, plastic casting
polyester, FRP, SMC(BMC), radome, synthetic foam, adhesives, printed circuit board substrate,
RTM, bowling, fan blades, & caulking materials, emulsion explosives, golf, sealant, pipeline
insulation materials, artificial marble, PVC, low density oil drilling, light cement, and other deep-sea buoy etc.
|
Product
|
Requirement
(g/cm3)
|
True Density (g/cm3)
|
|
|
Minimum
|
Maximum
|
||
|
YSHB-8
|
0.20
|
0.18
|
0.22
|
|
YSHB-9
|
0.25
|
0.23
|
0.27
|
|
YSHB-10
|
0.32
|
0.30
|
0.34
|
|
YSHB-11
|
0.38
|
0.36
|
0.40
|
|
YSHB-12
|
0.40
|
0.38
|
0.42
|
|
YSHB-13
|
0.46
|
0.44
|
0.48
|
|
YSHB-14
|
0.60
|
0.57
|
0.63
|
3. Nitrogen Isostatic Crush Strength
|
Product
|
Test Pressure
(MPa/Psi)
|
Target Fractional Survival |
Minimum Fractional Survival |
|
YSHB-8
|
3.5/500
|
90%
|
80%
|
|
YSHB-9
|
5/750
|
90%
|
80%
|
|
YSHB-10
|
14/2000
|
90%
|
80%
|
|
YSHB-11
|
38/5500
|
90%
|
80%
|
|
YSHB-12
|
28/4000
|
90%
|
80%
|
|
YSHB-13
|
41/6000
|
90%
|
80%
|
|
YSHB-14
|
55/8000
|
90%
|
80%
|
4.Thermal Stability
Appreciable changes in glass microspheres properties may occur above 600°C depending on
temperature and duration of exposure.
5.Chemical Resistance
In general, the chemical properties of hollow glass microspheres resemble those of a soda-lime
|
Product
|
Thermal Conductivity
(W·m-1·K-1) at 20°C
|
|
YSHB-8
|
0.039
|
|
YSHB-9
|
0.045
|
|
YSHB-10
|
0.050
|
|
YSHB-11
|
0.054
|
|
YSHB-12
|
0.056
|
|
YSHB-13
|
0.062
|
|
YSHB-14
|
0.074
|
7. Flotation
|
Product
|
Floaters (% by bulk volume)
|
|
|
Typical
|
Minimum
|
|
|
YSHB-8
|
96%
|
93%
|
|
YSHB-9
|
96%
|
93%
|
|
YSHB-10
|
96%
|
92%
|
|
YSHB-11
|
95%
|
92%
|
|
YSHB-12
|
95%
|
92%
|
|
YSHB-13
|
95%
|
92%
|
|
YSHB-14
|
95%
|
92%
|
|
Grade
|
Oil Absorption（By true density） g/cm3
|
|
YSHB-8
|
0.644
|
|
YSHB-9
|
0.580
|
|
YSHB-10
|
0.571
|
|
YSHB-11
|
0.450
|
|
YSHB-12
|
0.447
|
|
YSHB-13
|
0.451
|
|
YSHB-14
|
0.499
|
9. Particle Size
|
Product
|
Particle Size(μm, by volume ) |
||||
|
10%
|
50%
|
90%
|
d50 |
Size
|
|
|
YSHB-8
|
35
|
65
|
120
|
68
|
2-150
|
|
YSHB-9
|
30
|
60
|
115
|
60
|
2-150
|
|
YSHB-10
|
25
|
55
|
105
|
55
|
2-130
|
|
YSHB-11
|
22
|
40
|
70
|
40
|
2-100
|
|
YSHB-12
|
25
|
50
|
90
|
48
|
2-100
|
|
YSHB-13
|
25
|
50
|
90
|
46
|
2-100
|
|
YSHB-14
|
25
|
50
|
85
|
43
|
2-95
|
10.pH
11.Appearance
Hollow glass microspheres remain free flowing for at least half a year from the date of shipment if
Each container will be labeled with:
Type of hollow glass microspheres.Name of manufacturer. Lot number and quantity in kilograms.
14.Storage and Handling
Store in dry, well ventilated and out of direct sunlight place. Have Waterproof Functions. Keep away from fire and heat. Stored apart with acids and not allowed mixed storage. With the suitable material for leakage in storage area.
Airtight operation and local exhaust. The operator should be treated professionally and observe
instructions seriously. The operator is suggested to wear self-inhalation filter type dust mask,
protective chemical safety glasses, and protective gloves. Avoid producing dust and get in touch with acids. Should be light when load and unload to avoid breakage of packages. Equipped with
emergency treatment equipment to avoid leakage.
15.Health and Safety Information
For product Health and Safety Information, refer to product label and Material Safety Data Sheet
(MSDS) before using product.
|
Product
|
A Box
(kg)
|
B Box
(kg)
|
Bigbag
(kg)
|
|
YSHB-8
|
10
|
13
|
240
|
|
YSHB-9
|
12.5
|
15
|
280
|
|
YSHB-10
|
15
|
22
|
350
|
|
YSHB-11
|
20
|
28
|
500
|
|
YSHB-12
|
20
|
28
|
550
|
|
YSHB-13
|
22
|
32
|
580
|
|
YSHB-14
|
30
|
40
|
750
|
|
|
|
A Box
|
B Box+Pallet
|
Bigbag+Pallet
|
|
Container type
|
Container size
|
41.5*41.5*52
|
50*50*50
|
89*89*220
|
|
20'GP
|
5.89*2.35*2.38
|
260 cartons |
160 cartons（10 pallets） |
10 pallets |
|
40'GP
|
12.03*2.35*2.38
|
540 cartons |
352 cartons（22 pallets） |
20 pallets |
|
40'HQ
|
12.03*2.35*2.68
|
675 cartons |
352 cartons（22 pallets） |
20 pallets |
